AN6282 REV 5
REQUIREMENTS:
1. Part or identifying number (PIN): PINs to be used for fuses acquired to this
specification sheet are created as follows:
AN6282 - 8 - XXX
Rated volumetric capacity (2 or 3 digit)
Dash number
Specification sheet number
Example: AN6282-8-20 indicates fuse, 0.5 inch OD tubing with rated capacity of 20
cubic inches.
2. Dimensions are in inches.
3. The airplane or engine manufacturer shall allow clearance for the maximum
dimensions shown on this drawing for installation.
4. Type II fuse will not reset itself without reverse flow.
5. AN6282-4 and AN6282-6 have been canceled. As replacement, use AN6282-8 with
adapter.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
