MIL-DTL-5498G
SHUTOFF
TO ATMOSPHERE
PRESSURE GAGE
TRANSFER CHAMBER
TO SEPARATE FLUID
AS AN AID IN
TEMPERATURE CONTROL
CYCLING MACHINE OR UNLOADING VALVE
FLUID
SHUTOFF
GAS
RESERVOI
TEST ACCUMULATOR
FLUID PUMP
RELIEF VALVE
THREE-WAY SELECTOR VALVE
SPEED OF CYCLING TO BE IN ACCORDANCE WITH TABLE 1
SPEED OF CYCLING MAY BE INCREASED OR RETURN FLOW
RESTRICTED BY USE OF VALVE RETURN LINE TO MEET
PRESSURE REQUIREMENTS DURING 2,500, 7,500, 12,500
AND 37,500 IMPULSE
FIGURE 2. Typical accumulator cycling test setup (steps 1 to 6).
9
