MIL-H-8890(ASG)
(c) Material, protective finishes and processing of each detail
part, including applicable specification (A suggested method
is by use of code numbers and tabulation.)
(d) Ratings: Pressure, and temperature.
(e) Operating medium.
(f) Proof and burst pressures.
( g) Operating characteristics: Pressure drop, leakage, interflow
or noninterflow, and operating limitations (quantitative).
(h) Operating forces and positions of mechanical cent.mls.
(l) Locking and safetying devices.
(m) Seals, with details of all special configurations and
justification for the use of special configuration.
(n) Electrical connectional, with sufficient detail to establish
mating connections.
(o) Operating cycle: opening and closing times.
(p) Duty cycle.
(q) Protective closures for shipping and storage.
( r) Schematic diagram: Flow and electrical.
3.15 Identification of product. -
3.15.1 Nameplate .- Each component shall be permanently and clearly marked
with the information specified in the detail specification. The markings shall
be metal stamped directly on the component, or on a nameplate, in letters not less
than 0.045 inch high. The nameplate shall conform to specification MIL-R-6906,
o
except the 125°C (257° F) shall be replaced with 650 F. The nameplate shall
have a nominal minimum thickness of 0.020 inch, except wraperound n~platis with
crimped ends may be 0.012 inch. The nameplate shall be securely attached to each
component by use of screws, rivets, drive screws, welding, wraparound, or other
approved method. Adhesives of any type shall not be used. The markings shall
not be attached to the mounting face. The nomenclature shall conform to Catalog-
ing Handbook H6-1 or SAE publication ARP243.
3.16 Workmanship.- All details of workmanship shall be of sufficiently
high quality to insure satisfactory operation and service life.
QUALITY ASSURANCE PROVISIONS
4.
4.1 Inspection responsibility. - The supplier is responsible for the per-
formance of all inspection requirements as specified herein. Except as otherwise
Specified, the supplier may utilize his own or any other inspection facilities
and services acceptable to the Government. Inspection records of the examination
and tests shall be kept complete and available to the Government as specified in
the contract or order. The Government reserves the right to perform any of the
inspections set forth in the specification where such inspections are deemed
necessary to assure supplies and services conform to prescribed requirements.
