TABLE I. Element dimensions.
Part or Identification
Capacity
A
Oil
Weight
Number (PIN)
gpm
+.000
displacement
dry max
wet (max)
lb.
-.063
cu in
AN6236-1
7.50
1.969
25
0.60
AN6236-2
15.00
4.000
40
0.90
AN6236-3
30.00
8.063
65
1.80
REQUIREMENTS:
1. Material: See MIL-F-5504, the procurement specification.
2. Finish: See MIL-F-5504, the procurement specification.
NOTES:
1. These elements are for use with hydraulic reservoirs.
2. These elements are qualified items; the suppliers are listed in QPL-5504.
3. Dimensions are in inches.
4. Tolerances are as specified in table I and on figure 1.
5. Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
