INCH-POUND
AN6248 Rev 3
21 April 2011
SUPERSEDING
AN6248 Rev 2
15 April 1981
DETAIL SPECIFICATION SHEET
PUMP-HYDRAULIC HAND, TYPE 3000
Inactive for new design after 24 January 1996.
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-5515.
7 MAX
2
1.531 MAX
.813
1.125
C
+.000
SYMMETRICAL ABOUTL
2.312
2.250
WIDTH
- .010
3.875
AT MOUNTING HOLES
CLEARANCE ALLOWED FOR
DISCHARGE PORT BOSS IN
HANDLE MOVEMENT USING
ACCORDANCE WITH "B" BOSS
ANY PIVOT IN SHADED AREA
FOR .250 OD TUBE (NO INTERNAL
CHECK VALVE)
SUCTION PORT BOSS IN ACCORDANCE
WITH "B" (SEE TABLE I)
FOR SIZE "A" (USE TABLE I) O.D. TUBE
C EXTREME HIGH
C MID-POSITION
L
L
PROVIDE A BUILT IN CHECK VALVE
POSITION OF
OF HANDLE
AT THIS POINT.
30° ± 2°
HANDLE
.250
35° ± 1°
2.250
1.125
30° ± 2°
1.031
C
L
C EXTREME LOW
L
POSITION OF
HANDLE
4.312 MAX RAD
1.125
.438
.625
.5
.375
DRILL .257
2.75 ± .005
3.125 MAX
2 HOLES FOR
MOUNTING
PIVOT MAY BE
ANYWHERE IN SHADED
AREA
.020 MAX RAD
.510 ± .005
1.625 MAX DIA
1.5 MAX DIA.
1.000 ± .001 DIA
DRILL .191
2.000 ± .010
FIGURE 1. Hydraulic hand pump.
AMSC N/A
FSC 1650
