AN6248 Rev 3
Inches
mm
Inches
mm
.001
0.03
1.000
25.40
.005
0.13
1.031
26.19
.010
0.25
1.125
28.58
.020
0.51
1.500
38.10
.191
4.85
1.531
38.89
.203
5.16
1.625
41.28
.250
6.35
2.000
50.80
.257
6.53
2.250
57.15
.375
9.53
2.313
58.75
.438
11.13
2.750
69.85
.500
12.70
3.125
79.38
.510
12.95
3.875
98.43
.625
15.88
4.313
109.55
.813
20.65
7.000
177.80
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances for three place decimals ±.010 inch (0.25 mm), angles ±0.5°.
FIGURE 1. Hydraulic hand pump - Continued.
REQUIREMENTS
Dimensions, see figure 1.
Part or Identifying Number (PIN), see table I.
TABLE I. PIN.
AN PIN
"A"
"B" BOSS
AN6248-1
3/8
.375
AND10050
AN6248-2
1/2
.5
AND10050
AN6248-3
1/2
.5
SAE-AS5202
AN6248-1 Inactive for new design after 17 January 1949, use AN6248-2.
AN6248-2 Inactive for new design after 18 April 1981, use AN6248-3.
Interchangeability: AN6248-1 is not interchangeable with AN6248-2 or AN6248-3. AN6248-3 may be
used in place of AN6248-2. AN6248-2 may not be used in place of AN6248-3.
Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-5515, this document references the following:
AND10050
SAE-AS5202
2
