MIL-DTL-5498G
RELIEF VALVE
PRESSURE REGULATOR OR ANY SUITABLE
IMPULSE CYCLING DEVICE
RESERVOIR
CALIBRATED
PRESSURE GAGE
BLEED VALVE
SHUTOFF VALVE
STRAIGHT LENGTH
OF TUBING
PUMP
OSCILLOGRAPH AND STRAIN
GAGE OR SIMILAR PRESSURE
PRESSURE PICKUP
PICKUP DEVICE.
DEVICE SHALL BE
LOCATED IN THIS
12
AREA ONLY
1
AN818 TUBE NUT ON
ACCUMULATOR FLUID PORT
FITTING TUBE AND NUT TO BE
REPLACE ACCUMULATOR
SAME SIZE AS FLUID PORT
WITH SAE AS5168 PLUG AT
THIS POINT FOR CALIBRATION
TEST ACCUMULATOR
Dimensions in inches.
FIGURE 3. Typical cycling and endurance test setup (step 7).
10
