MIL-DTL-5498G
2.4 Order of precedence. Unless otherwise noted herein or in the contract, in the event of
a conflict between the text of this document and the references cited herein (except for related
specification sheets), the text of this document takes precedence. Nothing in this document,
however, supersedes applicable laws and regulations unless a specific exemption has been
obtained.
3. REQUIREMENTS
3.1 Qualification. The accumulators furnished under this specification shall be products
that are authorized by the qualifying activity for listing on the applicable qualified products list
3.2 Precedence. The requirements of SAE AS8775 apply as requirements of this
specification. If there is a conflict between the two documents, MIL-DTL-5498 shall govern.
3.3 Design and construction. Accumulators shall be designed and constructed to contain
gas and hydraulic fluid under pressure. The accumulator shall be provided with a fluid port, a
gas port, and a suitable piston type separator to separate the fluid and the gas within the
accumulator. Accumulators shall contain a safety provision to ensure dissipation of the
accumulator gas pressure and fluid pressure before any component parts can be disassembled.
1.000
1.000
0.125 MIN
0.750
0.062
H
H
G
E
D E
FLUID CONNECTION BOSS
GAS CONNECTION BOSS
SAE AS5202 FOR TUBE
THREAD, SAE AS5202-05
SIZES SHOWN
0.750
C
B
A
NOTE: Dimensions are in inches. Unless otherwise specified, the tolerances are ±0.031.
FIGURE 1. 3,000 psi cylindrical hydraulic accumulator.
