MIL-DTL-5508 Fuses, Aircraft Automatic Quantity-Measuring, HydraulicThis specification covers aircraft automatic quantity-measuring hydraulic fuses for use in SAE AS8775 Type I aircraft hydraulic systems.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21


MIL-DTL-5508C
Reservoir
Flowmeter
Relief valve
Check
valve
Bypass
Pump
valve
Safety
relief valve
4-way directional
Fuse
control valve
Pressure gage
Pressure gage
FIGURE 3. Typical installation for flow tests.
